川消消防水泵接合器和消火栓,，可不要搞混了,！
來源：http://n3462.cn/ 日期：2023-05-05
消防水泵接合器是消防隊使用消防車從室外水源取水，向室內管網供水的接口,。川消消防水泵接合器和消火栓,，可不要搞混了！
The fire pump adapter is an interface where the fire brigade uses a fire truck to take water from an outdoor water source and supply water to the indoor pipeline network. Don't confuse the fire pump adapter and fire hydrant of Chuanxiao!
消防水泵接合器的作用
The function of fire pump adapter
建筑物遇大火消防用水不足時,，可通過它將水送室內消防給水管網,，補充消防用水量的不足室內消防水泵發生故障時，消防車從室外消火栓取水,，通過它將水送室內消防給水管網,；室內消防用水不足，而消防水泵工作正常時,，可通過它將水送到位于建筑物內的消防水池室內,；消防水泵壓力不足時，可通過它將水送室內消防給水管網,。
When a building encounters a fire and there is insufficient water for firefighting, it can be used to send water to the indoor firefighting water supply network. When the indoor firefighting water pump fails, the fire truck takes water from the outdoor hydrant and sends it to the indoor firefighting water supply network through it; When the indoor fire water is insufficient and the fire pump is working normally, it can be used to deliver water to the fire pool located inside the building; When the pressure of the fire water pump is insufficient, it can be used to send water to the indoor fire water supply network.
消防水泵接合器有哪些分類
What are the classifications of fire pump adapters
按安裝型式：地上式,、地下式、墻壁式和多用式
According to installation type: above ground, underground, wall, and multi-purpose
接合器出口的公稱通徑： 100mm,、150mm
Nominal diameter of adapter outlet: 100mm, 150mm
接合器公稱壓力：1.6MPa,、2.5MPa、4.0MPa
Connector nominal pressure: 1.6MPa, 2.5MPa, 4.0MPa
接合器連接方式：法蘭式,、螺紋式
Connection method of adapter: flange type, threaded type
那么消火栓與消防水泵接合器有哪些區別,？
So what are the differences between fire hydrants and fire pump adapters?
01
01
用法不一樣
Different usage
消防水泵接合器通常與建筑物內的自動噴水滅火系統或消火栓等消防設備的供水系統相連接。消火栓主要供消防車從市政給水管網或室外消防給水管網取水實施滅火,也可以直接連接水帶,、水槍出水滅火
The fire pump adapter is usually connected to the automatic sprinkler system or the water supply system of fire equipment such as fire hydrants in buildings. Fire hydrants are mainly used by fire trucks to take water from the municipal water supply network or outdoor fire water supply network for extinguishing fires, and can also be directly connected to water hoses and water guns for extinguishing fires
02
02
類型不一樣
Different types
消防水泵接合器按其安裝型式可分為地上式,、地下式、墻壁式和多用式,，消防栓分室內消火栓和室外消火栓
Fire pump adapters can be divided into aboveground, underground, wall, and multi-purpose types according to their installation types. Fire hydrants are divided into indoor and outdoor fire hydrants
03
03
作用不一樣
The effect is different
消防水泵接合器一般用于高層建筑.消防栓主要作用是控制可燃物、隔絕助燃物,、著火源
Fire pump adapters are generally used in high-rise buildings. The main function of fire hydrants is to control combustibles, isolate combustibles, and eliminate ignition sources
04
04
距離不一樣
Different distances
墻壁式室外消防水泵接合器的安裝高度距地面宜為0.7m,。消火栓距路邊的距離不宜大于2m；消火栓周圍應留有消防隊員的操作場地,故距建筑外墻的距離不宜小于5m,。同時,，為便于使用,，規定了消火栓距被保護建筑物不宜超過40m
The installation height of the wall type outdoor fire pump adapter should be 0.7m above the ground. The distance between the fire hydrant and the roadside should not be greater than 2 meters; There should be an operating area for firefighters around the fire hydrant, so the distance from the exterior wall of the building should not be less than 5m. Meanwhile, for ease of use, it is stipulated that the distance between fire hydrants and protected buildings should not exceed 40m
以上就是川消小編為你講解的關于消防水泵接合器和消火栓的區別，希望能夠給您好的幫助,，還有什么疑惑或者需求,，歡迎您隨時來我們網站http://n3462.cn進行咨詢！
The above is the difference between fire pump adapters and fire hydrants explained by the editor of Sichuan Xiaoxiao. We hope to be of great help to you. If you have any doubts or needs, please feel free to come to our website at any time http://n3462.cn Consulting!
